| MOQ: | 1 Unit |
| Standard Packaging: | Using Carton, fumigated wood pallet and steel pallet |
| Delivery Period: | 45-60 Working days |
| Payment Method: | T/T, L/C |
| Supply Capacity: | 5000units per year |
New Energy Underground Dump Mini Truck BJ-4E Economical Mining Truck
Overall Introduction
The Electric Underground Dump Dumper is an electric transport vehicle designed for underground engineering, tunnelling and mining operations. It combines the environmental advantages of the electric drive system with the efficient loading and unloading capability of the tipper, aiming to provide a safe, efficient and environmentally friendly material handling solution. The following are the main features and performance parameters of the electric underground dump dumper:
Design features:
Electric drive system: Adopting advanced electric motor and battery pack, no tail gas emission, reducing the pollution of underground operation environment.
Self-unloading mechanism: Equipped with hydraulic system, it can complete the unloading of materials quickly and easily and improve the operation efficiency.
Manoeuvrability: The cockpit is reasonably designed and easy to operate, even in the narrow underground space, it can be flexibly controlled.
Safety: Equipped with emergency stop button, anti-skid tyres, brake system and other safety facilities to ensure the safety of drivers and operators.
Performance parameters:
Load capacity: the vehicle is rated to carry 4 tonnes.
Mileage: Load range can reach 7.5 hours to meet the requirements of continuous operation.
Climbing ability: the maximum load climbing degree is 14 ° with good climbing performance, can be in the underground complex terrain smooth driving.
Speed: Maximum travelling speed is 25km/hour, which ensures both operational efficiency and safety.
Advantages:
Environmentally friendly: no exhaust emissions, reducing pollution of the underground environment.
Economical: Electric drive reduces energy costs and maintenance costs.
Efficient: Self-dumping mechanism simplifies the loading and unloading process and improves operational efficiency.
Safety: Good controllability and safety design reduces operational risks.
Parameters of BJ-4E New Energy Underground Dump Truck
| Parameters of BJ-4E New Energy Underground Dump Truck | |||
| Dimensions (L x W x H) |
4091x1300x2024mm (axle width 1505mm) |
Maximum speed backward | 25Km/h |
| Overall mass | 2300kg | Traveling motor power | 11kw |
| Trunk volume |
1.4lm |
Front steering axle brand | 130 |
| Rated load capacity | 4000kg | Rear drive axle brand | Wan Teng Axle |
| Maximum traction force | 30KN | Rear drive axle model | 1069 |
|
Maximum machine height when unloaded |
2924mm | Lithium battery pack | Ningde Times battery cell |
| Loading height | 1421mm | Lithium battery pack | Lithium ternary |
| Minimum ground clearance | 300mm | Li-ion Battery Capacity | 470Ah 72V |
|
Minimum turning radius (outside) |
6050mm | Li-ion Battery Pack Energy | 33Kwh |
| Approach angle | 28° |
Charging System Input Voltage |
220V AC |
|
Climbing capacity (heavy load) |
14° |
Charging system output Voltage |
76V DC |
| Maximum Lift Angle | 45° |
Charging system output current |
60A |
| Trunk Lifting Time | 15s | No-load leveling time |
11.5h |
| Trunk Lowering Time | 10s |
Heavy load level running time |
7.5h |
| Maximum speed forward | 25Km/h | Average level running time | 9.5h |
| Charging time | 8h | ||
Customer Cases
FAQ
Q1 What types of payment terms are acceptable?
A:We acceptable T/T, L/C
Q2 What is your minimum order requirement?
A: 1 unit.
Q3 What is your distributor support policy in international markets?
A:We invest technologies and equipment, while our partners provide lands,workshops,
funds, management and marketing.
1. Offering you an easy and quick approach to entering automobile industry
2. Assembling vehicles using KD parts to save cost.
3. Our professional team prepares architectural design and assembly design based
on the end products our partners choose.
4. Our engineers provide job training and technical service on site.
5. Quality control system makes sure vehicles come off our assembly lines get
universal quality
Q4 What is your shipping method and delivery time?
A: Transported by air, container, ro-ro ship. LCL quantities allow one vehicle to be shipped. Orders will be sent via FCL shipping. Usually the delivery time is 15 to 25 days after receiving the deposit.
Q5 What are the advantages of working with us?
A:1. Tariff Gap:Import tariff gap between KD and CBU would be totally translated to profit.
2.Competitive:Auto technologies in China have improved greatly in the last decade.
3. Cheap:Components and parts from China are much cheaper than western counterparts.
4. After-sale Service: Easier access to spare parts and technologies than selling CBU
5. Low Initial Investment:Starting from SKD with only assembly line for only 1 million USD
|
|
