| MOQ: | 1 |
| Price: | USD10,899.00-USD11,199.00 / Unit |
| Standard Packaging: | Nude Packing if CBU, Wooden Case + Pallet + Steel Frame + Carton if SKD or CKD |
| Delivery Period: | 60 working days |
| Payment Method: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Capacity: | 100000 Units per Year |
Auto Assembling of Small Pickup Trucks Economic Diesel 4*4 Pick Up Trucks in Knocked Down Kits
Six main advantages of assembling the Small Pickup Trucks Economic Diesel 4*4 Pick Up Trucks in local:
--- Save Customs Duty and other tax;
--- Save Shipping Cost;
--- Increase margin;
--- Improve competitiveness;
--- Develop your local industry;
--- Creat job opportunities.
1. Description of the Small Pickup Trucks Economic Diesel 4*4 Pick Up Trucks:
| Economic Pickup Truck - Model 1029 Double Cabin | ||
| VEHICLE TYPE | 1029LD2YEA | |
| Body Parameter | Length x Width x Height(mm) | 5590×1760×1760 |
| Wheelbase(mm) | 3380 | |
| Front Wheel-base | 1460 | |
| Rear Wheel-base | 1470 | |
| Gurb Mass(kg) | 1662 | |
| Gross Vehicle Weight(kg) | 2487 | |
| Load Mass(kg) | 500 | |
| Seating capacity | 5 | |
| Length×Width×Height(Cargo inner)(mm) | 1825×1440×505 | |
| Tire Size | 235/70R16 | |
| Ground Clearance(mm) | 215 | |
| Oil tank capacity(L) | 60 | |
| Power Parameter | Fuel | Diesel |
| Engine | FAW CA4D28C4-1 | |
| Emission Standard | Chinese Level Ⅳ | |
| Displacement(cc) | 2771 | |
| Fuel consumption(L/100km) | 8 | |
| Engine Type | Water-cooled, inline four-stroke, turbocharged, common rail direct injection | |
| Maximum Power(Kw/rpm) | 70±3 / 3600 | |
| Maximum Torque(N.m/rpm) | 225±5/(1600～2600) | |
| Compression ratio | 17.2:1 | |
| Max.vehicle speed(km/h) | 120 | |
| Transmission | Transmission Type | 5MT |
| Chassis Parameter | Approach Angle(°) | 29 |
| Departure Angle(°) | 26 | |
| Brake Type | Front Disc Brake/ Rear Drum Brake | |
| Suspension(Front/Rear) | independent suspension /Leaf spring type non-independent suspension | |
| MinimumTurning Diameter (m) | 13 | |
| Drive Mode | 4WD | |
| Steering Type | Recirculating ball steering gear | |
| Exterior Equipment | Aluminum alloy step | ● |
| Alloy rim | ● | |
| body color door handle | ● | |
| Fashion sport roll bar | ● | |
| Rear bumper | ● | |
| Cargo coating | ● | |
| Metallic Paint | ● | |
| Interior Equipment | 2018 new inner triming | ● |
| Adjustable steering wheel | ● | |
| Cloth seat | ● | |
| Front row three-point safety belt | ● | |
| Remote control central door lock | ● | |
| power window | ● | |
| Environment heat and cold air-conditioner | ● | |
| FM+MP3 | ● | |
| Loud Speaker | ● | |
| Safety | High rigidity vehicle body | ● |
| Front fog light | ● | |
| SABS | ● | |
| Interior anti-glare rear view mirror | ● | |
| electri-driven rear- view mirror(lens) | ● | |
| Remark: 1. "●"Available "—"Not Available; 2. The above quotations are for mini order of 10 units, for large order, we can discuss, valid for 30 days from the issuing date. 3. Details subject to the agreement by both parties. | ||
2. Our service and our capability:
In this project, our Chinese company will provide technology support to your company, by sending engineers and technicians to your local place to training your staff, and passing on our China's knowledge your staff (including but not limited to the vehicle manufacturing skills, management system of the vehicle assembly factory, etc. ...); in the same time, supply the complete vehicle SKD/CKD parts for being re-assembled in your local place as well as the assembly equipments; and factory design, equipment layout design in the factory, ... ...
3. Our Cooperation Mode:
A. Trade Agency
At first stage, we can do exporting & importing trade business, gradually build the mutual trust and favorable business relationship, and then develop to project cooperation. If our partner hasn’t gathered enough capital to do the project, this cooperation way is recommended to accumulate funds and experience for the project start later.
B. Turnkey Project/ Technology Transfer Mode
In this project, our oversea partners take 100% shareholdings, and our Group assists you with technology and all necessary equipment of the factory, all in "turn-key project" mode. You pay for the technology transfer, while we help you to establish the assembly factory and provide you automobile parts in SKD or CKD status for assembling in order to cut your cost and simplify the production process. We provide you with all the necessary technology assistance and auto parts till you can master all required technologies and be capable to assemble vehicles on your own completely.
C. Joint Venture Mode
1st way: we take 15% of the shareholding and being responsible for offering the Business Plan Assistance, Production Line Layout & Plant Design, Equipment Installation & Debugging, Technology Support, Worker Training, Manufacturing, Production & Quality Control Management, Advice & Guidance for Sales & After-Sales, Development Plan & Solution, etc.
2nd way: we take 35% of the shareholding and being responsible for offering the Key Equipments, Business Plan Assistance, Production Line Layout & Plant Design, Equipment Installation & Debugging, Technology Support, Worker Training, Manufacturing, Production & Quality Control Management, Advice & Guidance for Sales & After-Sales, Development Plan & Solution, etc.
3rd way: we take more than 35% of the shareholding and being responsible for offering the Capital, some Credit based on reliable guarantee, Key Equipments, Business Plan Assistance Production Line Layout & Plant Design, Equipment Installation & Debugging, Technology Support, Worker Training, Manufacturing, Production & Quality Control Management, Advice & Guidance for Sales & After-Sales, Development Plan & Solution, etc.
4. Requirements on our Cooperation Partners:
If you start with trade business, a necessary amount of funds for vehicle cycle purchase, a decent showroom for auto exhibition and a kind of repair shop, enough. However, if you want to start the auto assembly plant project, you have to reach the following subjective and objective requirements:
• Workshop / Factory: 5000-8000 square meters to start, and a piece of an industrial land around 20000-25000 square meters for expansion in future.
• Fund: You need to have necessary economic strength & investment capacity, specifically, two million USD at least, excluding land and workshop.
• Market channel: You’d better have your own car sales channel & network, automobile related business.
• Auto import tariff policy: The import tariff policy in your country is very important, the difference of import tariff between CKD (completely knocked down) and CBU (complete built unit) shall be at least 30-35%; for example, if the import tariff on CBU is 35%, so it must be 5% or free on CKD. It is the key factor to set up an assembly plant in local overseas, however, if the import tariff on CKD is almost the same with that on CBU, the auto plant will have not any profit space and it makes no sense to start it.
• Good relationship with government: it can give you good and preferential policies or incentives on this automobile assembly project, and even it can bring you big orders for the assembly plant.
5. Process of our Auto KD Assembly Project:
6. Finally, this Auto KD Assembly Project is Profitable:
If you are interested, contact us now, we will never make you disappointed ! Seize this opportnity, you win, we win, win-win !!
Looking forward to your cooperation!!
Our Contact:
Lucky Peng (Ms.)
China Big S & T Dev (Group) Co., Limited
Website: www.auto-assemblyplants.com; www.chainautoassembly.com; www.china-big.com.cn
Email: project11@chainautoassembly.com; project1@chainautoassembly.com; yingqingpeng@china-big.com.cn;
Skype: chongqingbig
Tel No. (WeChat / Whatsapp / Viber): 15223551381
|
|
