Special Purpose Vehicle Self-dumping Rubbish Truck C5 With Big Capacity

Special Purpose Vehicle Self-dumping Rubbish Truck C5 With Big Capacity

MOQ: 1 unit
Standard Packaging: Using Carton, fumigated wood pallet and steel pallet
Delivery Period: 45-60 Working days
Payment Method: T/T, L/C
Supply Capacity: 5000units per year
Detail Information
Place of Origin
China
Brand Name
BIG AUTO
Certification
CCC
Model Number
BIG C5
Product Name:
Self-dumping Rubbish Truck C5
Overall Dimensions:
9710,9610,9460,9410,9360,9310,9260,9210,9160,9110,9010,8960,8910,8860,8760×2550,2500×3490,3500,3550,3680,3910(mm)
Container Size:
7000,6800,6500,6300,6200,6000,5800×2410,2350,2400,2300,2150,2100×800,900,950,1000,1100,1200,1300,1350,1400,1450,1500(mm)
Gross Mass:
31000(Kg)
Curb Weight:
15500(Kg)
Rated Load Mass:
15370(Kg)
Approach/Departure Angle:
19/13,19/14,19/15,19/16,19/17,19/18(°)
Front/Rear Overhang:
1492/2093,1492/1943,1492/1843,1492/1793,1492/1693,1492/1593,1492/2068,1492/1918,1492/1818,1492/1768,1492/1668,1492/1568,1492/1993,1492/1743,1492/1968,1492/1718(mm)
Fuel Type:
Diesel
Emission Standard:
China Ⅵ
Minimum Order Quantity:
1 unit
Packaging Details:
Using Carton, fumigated wood pallet and steel pallet
Delivery Time:
45-60 Working days
Payment Terms:
T/T, L/C
Supply Ability:
5000units per year
Highlight:

C5 Rubbish Truck

,

Self dumping Rubbish Truck

,

Big Capacity Rubbish Truck

Product Description

Special Purpose Vehicle Self-dumping Rubbish Truck C5 With Big Capacity







Product Features:
1. used for the transport of sludge, gravel, coal, slag and other materials.


2. Light dead weight: through CAE auxiliary analysis for lightweight design, the dead weight is lighter, about 1.5-2 tonnes lighter than the conventional tipping trucks, which saves fuel consumption and low cost.


3. High strength: the box is made of 510/600/700 high-strength and NM400/NM450 high-wear-resistant special steel (the highest strength can be up to 1450Mpa), which makes the box stronger and more beautiful in appearance, and the product has a higher value.


4. Good stability: low centre of gravity design, 60mm lower than the conventional cargo box, in the case of the same speed braking, the vehicle is more stable, to achieve all-weather conditions of different operating scenarios to easily cope with.


5. Clean unloading: the box body adopts U-shape design, the side plate and the bottom plate are folded into shape, the interior is smooth without hanging materials, and the unloading is smooth and easy to flush.


6. Safety and environmental protection: Combined with the concept of environmentally friendly urban transport, it can be equipped with tarpaulin or metal (iron/aluminium alloy optional) sealing roof in compliance with regulations. The top cover adopts the domestic top design, the inner and outer groove structure is more durable, when the environmental protection cover is not closed tightly, the engine can only idle, can not be normal refuelling normal driving, to ensure safety.


7. Large volume: Larger volume rate, higher yield, about 0.2-0.5 cubic metres increase in volume compared with ordinary compartments.





Product Parameter

Dimension

9710,9610,9460,9410,9360,9310,9260,9210,9160,9110,9010,8960,8910,

8860,8760×2550,2500×3490,3500,3550,3680,3910(mm)



Cargo compartment dimensions

7000,6800,6500,6300,6200,6000,5800×2410,2350,2400,2300,2150,

2100×800,900,950,1000,1100,1200,1300,1350,1400,1450,1500(mm)

Gross mass

31000(Kg)

Rated load mass

15370(Kg)

Approach/Departure Angle

19/13,19/14,19/15,19/16,19/17,19/18(°)

Front/Rear Suspension

1492/2093,1492/1943,1492/1843,1492/17931492/1693,

1492/1593,1492/2068,1492/19181492/1818,1492/1768,1492/1668,

1492/1568,1492/1993,1492/1743,1492/1968,1492/1718(mm)

Fuel Type

Diesel

Emission standard

China Ⅵ

Axle load

6500/7000/17500 (biaxial group)

Wheelbase

1800+2525+1350,1800+2500+1400,1800+2825+1350,1800+2800+1400,

1950+2525+1350,1950+2500+1400,1950+2825+1350,1950+2800+1400(mm)

Number of axles

4

Maximum vehicle speed

88(km/h)

Number of tyres

12

Tyre specification

12.00R20 18PR,11.00R20 18PR,12R22.5 18PR

Fuel consumption

39.11,39.11,39.11,39.30,39.30,39.52,39.09,39.09,39.44,39.44,39.

25,39.25,39.25,39.25(L/100Km)

Number of spring plates

4/4/5,5/5/5,4/4/10,7/7/10,9/9/10,

11/11/10,11/11/12,14/14/12,9/9/12

Front wheelbase

2022/2022,2041/2041(mm)

Rear wheelbase

1830/1830,1860/1860(mm)

Unloading method

Rear Unloading

Connection method

Bolt connection





Detailed Picture:

Special Purpose Vehicle Self-dumping Rubbish Truck C5 With Big Capacity 0
