CLTC Has A Range Of 510 Kilometers Electric Car Z03 Max Speed Top Performance
Z03 General Introduction:
Ⅰ. Appearance Introduction
Body front: Z03 front face adopts closed grille design, and the shield-shaped black grille in the center mesh of the lower bumper further enhances the sense of sportiness. The front face configuration can be seen with LED daytime running lights, LED high and low beam headlights, front camera and ACC millimeter wave radar unit.
Side of the body: the length, width and height of the Hetron Z03 is 4602/1900/1645 millimeters, the wheelbase is 2750 millimeters, positioning is a compact SUV. side design, the waistline above the door handle through the front and rear, pulling up the stance of the body, looks more spiritual.
Rear: The highlight is the penetrating LED taillight belt, and the internal light beads are more beautiful when lit. In addition, there is a large upper spoiler above the rear, and the center is through-hole.
II. Interior Introduction:
Steering wheel: the steering wheel is wrapped in leather and is comfortable to grip. The function buttons on the steering wheel are set up with touch control for a full sense of technology.
Instrument panel: the instrument panel is a 10.25-inch LCD instrument, the display information inside the instrument panel is rich, and the internal UI design is relatively simple, easy to use. In addition, most of the functions in the car are integrated in the screen, in the lower part of the screen integrated vehicle design, air conditioning settings, 360 images, seat function settings and other commonly used buttons, daily use is more convenient to find the corresponding functions.
Seats: Z03 offers 4-seat and 5-seat models, the seat color scheme and the center control has maintained the same, the seat material is covered with leather, the softness of the seat cushion and backrest are more comfortable. The front seats support power adjustments for the front, rear and backrest for the main driver, and manual adjustments for the passenger.
III. Power Introduction:
Z03 adopts a front-mounted single motor with a maximum power of 135 kW and a maximum torque of 225 Nm. The battery pack is matched with a lithium iron phosphate battery with a capacity of 64.6 kWh, with a fast charging time of 0.6 hours to 80% and a slow charging time of 10.7 hours, and a CLTC range of 510 kilometers. In terms of suspension, the Hetron Z03 is paired with a front MacPherson independent suspension and a rear torsion beam non-independent suspension.
| Z03 Technical Specifications | |
| DRIVE MOTOR | DESCRIPTION |
| Motor Type | permanent magnet synchronous |
| Number of Driving Motors | single motor |
| Motor Layout | Front |
| Maximum Power(kW) | 135 |
| Maximum Torque(N.m) | 225 |
| Maximum speed(Km/h) | 140 |
| BATTERY PACK | DESCRIPTION |
| Battery Type | lithium iron phosphate battery |
| Battery capacity(kW.h) |
55.4 |
| CLTC range(km) |
430 |
| Quick charging time(30% to 80%)(h) |
≥36min |
| Slow charging time(10% to 100%)(h) |
≥10h |
| EXTERIOR | DESCRIPTION |
| Length*Width*Height(mm) |
4602*1900*1600 |
| Wheelbase(mm) |
2750 |
| Wheel Track Front/Wheel Track Rear(mm) |
1610/ 1610 |
| Approach angle/ Departure angle(°) |
14/16 |
| Curb Weight(Kg) | 1230 |
| Maximum full load mass(Kg) | 1605 |
| CHASSIS | DESCRIPTION |
| Front Suspension | Macohereson independent suspension |
| Rear Suspension | Torsion beam suspension |
| Front Brakes/ Rear Brakes | Ventilated discs/ Discs |
| Parking Brake | Electric Parking Brake |
| ABS/EBD | Standard |
| Drive Type | FF |
| Shift Mode |
Knob-type electronic shift |
| Steering Form |
Electric Power Steering (EPS) |
| Tire Size |
215/ 55 , R17 |
| BODY | DESCRIPTION |
| Body Structure | Five-door, five-seat SUV |
| Seats Number | 5 |
| Seat Belt Type | three-pointed |
| Number of Airbags | 2 |
| Air Conditioning |
Automatic air conditioning |
Detailed Pictures
