Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In

Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In

  • Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In
  • Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In
  • Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In
  • Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In
  • Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In
  • Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In
  • Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In
Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In
Product Details:
Place of Origin: CHINA
Brand Name: BIGST
Model Number: 400
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 14,999 - USD 22,691/ unit
Packaging Details: Nude Packing if CBU, Wooden Case + Pallet + Steel Frame + Carton if SKD or CKD
Delivery Time: 60 Working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10,000 Units per Year
Contact Now
Detailed Product Description
Project: Car Assembly Seating: 5/7
The Motor Type: Permanent Magnet Synchronous Machine Rated Power(Kwh): 55-60
Max. Torque(Nm): 250-280 Max. RPM: 12000
Total Range: 600-800 Battery System Rated Voltage V: 352
Top Speed: 130-140
High Light:

Hybrid Electric MPV 7Seats Cars

,

EV MPV 5-7-Seats Cars

,

1790mm MPV 7Seats Cars

Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 0  Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 1  Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 2  Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 3  Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 4  Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 5  Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 6







Product Details:
Place of Origin: CHINA
Brand Name: EV
Model Number: BGST-EV-400
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 14,999 - USD 22,691/ unit
Packaging Details: Nude Packing if CBU, Wooden Case + Pallet + Steel Frame + Carton if SKD or CKD
Delivery Time: 60 Working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10,000 Units per Year





Detailed Product Description
Motor: AC Asynchronous Motor Engine Type: Batteries
Length: 4650mm Width: 1790mm
Height: 1760mm Transmission: Automatic
Drive Type: RHD/LHD Full load mass kg: 2175
Project: Car Assembly Item: Auto Assembling
Min. Groundclearance: 130mm Rated load weight kg: 525mm
Seats 5/7
Tire: 205/55R17 Motor power (kW): 60
Maximum Speed: 120km/h
High Light: MPV  Electric car





Car Assembly Line for MPV Electric Car in SKD/CKD to Save Customs Duty





Six Advantages of assembling MPV Electric Mimi car Powered by Battery local:



--- Save Customs Duty and other tax;

--- Save Shipping Costs;

--- Increase margin;

--- Improve competitiveness;

--- Develop your local industry;

--- Create job opportunities.



1. Description of the Electric Car Powered by Battery:





EV400 Taxi & online Car-hailing special version
  1, Range 200km 2, Range 400km 3, Custom Super Fast Charge 15 minutes
■ model Online car-hailing
Price(yuan) $14999 $19,230 $22,691
技术参数Technical parameters
Length x width x height mm 4650*1790*1760 4650*1790*1760 4650*1790*1760
The shaft from mm 2765 2765 2765
Wheel pitch (front/rear) mm 1512/1532 1512/1532 1512/1532
Tire size 205/55R17 205/55R17 205/55R17
Minimum ground clearance (full load)mm 130 130 130
Minimum turning radius m 5.55 5.55 5.55
Maximum speed km/h 120 120 120
Ready mass kg 1650 1650 1650
Full load mass kg 2175 2175 2175
Rated load weight kg 525 525 525
Operation method continued mileage km 301 301 301
0-50km/h acceleration time s ≤5 ≤5 ≤5
seating 7 7 7
电机/电池参数 Motor/battery parameters
The motor type Permanent magnet synchronous machine Permanent magnet synchronous machine Permanent magnet synchronous machine
Motor model TE1221A2 TE1221A2 TE1221A2
System input voltage (DC) /V 250-360-420 250-360-420 250-360-420
Rated/peak power kW 35/70 35/70 35/70
Maximum speed r/min 13000 13000 13000
Maximum torque Nm 200 200 200
Drive motor number 1 1 1
Battery type Ternary lithium battery Ternary lithium battery Ternary lithium battery
Total energy storage of energy Storage Device (KWH) 25 46 46
Battery system rated voltage V 352 352 352
Fast charging/slow charging 2 / 1 2 / 1 2 / 1
0-90% fast charging time 30-45 minutes 30-45 minutes 15 minutes
Slow filling time 6 hours 6 hours 6 hours
On-board charging gun (including adapter) Optional Optional Optional
变速箱/底盘/转向/车轮/制动 Transmission/chassis/steering/wheels/braking
Transmission type Electric single-speed transmission Electric single-speed transmission Electric single-speed transmission
Block a number 1 1 1
Transmission type Fixed gear ratio gearbox Fixed gear ratio gearbox Fixed gear ratio gearbox
Drive form Lead precursor Lead precursor Lead precursor
Front/rear suspension system McPherson independent suspension/torsion beam non - independent suspension McPherson independent suspension/torsion beam non - independent suspension McPherson independent suspension/torsion beam non - independent suspension
To type Electric power Electric power Electric power
Front/rear braking system Ventilated disc type/disc type Ventilated disc type/disc type Ventilated disc type/disc type
Parking brake type Manual parking Manual parking Manual parking
Front and rear tire specifications 205/55 R17 205/55 R17 205/55 R17
Spare tire specifications and dimensions - 205/55 R17 205/55 R17
rims 17 inch iron ring 17 inch aluminum ring 17 inch aluminum ring





Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 7  Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 8  Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 9  Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 10  Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 11





2. Our service and our capability:



In this project, our Chinese company will provide technology support to your company, by sending engineers and technicians to your local place to training your staff, and passing on our China's knowledge your staff (including but not limited to vehicle manufacturing skills, the management system of the vehicle assembly factory, etc. ...); in the same time, supply the complete vehicle SKD/CKD parts for being re-assembled in your local place as well as the assembly equipments; and factory design, equipment layout design in the factory, ... ...



                                                 Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 12



3. Our Cooperation Mode:


A. Trade Agency



At first stage, we can do exporting & importing trade business, gradually build the mutual trust and favorable business relationship, and then develop to project cooperation. If our partner hasn’t gathered enough capital to do the project, this cooperation way is recommended to accumulate funds and experience for the project start later.


B. Turnkey Project/ Technology Transfer Mode



In this project, our oversea partners take 100% shareholdings, and our Group assists you with technology and all necessary equipment of the factory, all in "turn-key project" mode. You pay for the technology transfer, while we help you to establish the assembly factory and provide you automobile parts in SKD or CKD status for assembling in order to cut your cost and simplify the production process. We provide you with all the necessary technology assistance and auto parts till you can master all required technologies and be capable to assemble vehicles on your own completely.


C. Joint Venture Mode


1st way: we take 15% of the shareholding and being responsible for offering the Business Plan Assistance, Production Line Layout & Plant Design, Equipment Installation & Debugging, Technology Support, Worker Training, Manufacturing, Production & Quality Control Management, Advice & Guidance for Sales & After-Sales, Development Plan & Solution, etc.



2nd way: we take 35% of the shareholding and being responsible for offering the Key Equipments, Business Plan Assistance, Production Line Layout & Plant Design, Equipment Installation & Debugging, Technology Support, Worker Training, Manufacturing, Production & Quality Control Management, Advice & Guidance for Sales & After-Sales, Development Plan & Solution, etc.



3rd way: we take more than 35% of the shareholding and being responsible for offering the Capital, some Credit based on reliable guarantee, Key Equipments, Business Plan Assistance Production Line Layout & Plant Design, Equipment Installation & Debugging, Technology Support, Worker Training, Manufacturing, Production & Quality Control Management, Advice & Guidance for Sales & After-Sales, Development Plan & Solution, etc.







4. Requirements on our Cooperation Partners:



If you start with a trade business, a necessary amount of funds for vehicle cycle purchase, a decent showroom for auto exhibition, and a kind of repair shop, are enough. However, if you want to start the auto assembly plant project, you have to reach the following subjective and objective requirements:



• Workshop / Factory: 5000-8000 square meters to start, and a piece of industrial land around 20000-25000 square meters for expansion in the future.



• Fund: You need to have the necessary economic strength & investment capacity, specifically, two million USD at least, excluding land and workshop.



• Market channel: You’d better have your own car sales channel & network, for automobile-related business.



• Auto import tariff policy: The import tariff policy in your country is very important, the difference of import tariff between CKD (completely knocked down) and CBU (complete built unit) shall be at least 30-35%; for example, if the import tariff on CBU is 35%, so it must be 5% or free on CKD. It is the key factor to set up an assembly plant in locally overseas, however, if the import tariff on CKD is almost the same as that on CBU, the auto plant will have not any profit space and it makes no sense to start it.



• Good relationship with government: it can give you good and preferential policies or incentives on this automobile assembly project, and even it can bring you big orders for the assembly plant.







5. Process of our Auto KD Assembly Project:



                                              Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 13







6. Finally, this Auto KD Assembly Project is Profitable:



                                              Hybrid Electric EV MPV 5-7-Seats Cars Ride Hailing Power And Plug In 14



If you are interested, contact us now, we will never make you disappointed! Seize this opportunity, you win, we win, win-win !!





Looking forward to your cooperation!!
